About equipment
Supporting host | SJ120-170 single screw extruder |
Screw length to diameter ratio (L/D) | 35:1 |
Screw speed (r/min) | 73-90 |
Main motor power (kw) | 132-220 |
Production capacity (kg/h) | 400-800 |
Mirror calender axis width × diameter mm | 1800×Φ500 |
Mirror calender shaft speed r/min | 0.15-3 |
Traction speed r/min | 0.15-3 |
Traction power kw | 4 |
Cutting power kw | 4 |
Unit dimensions (length × width × height) m | 45-55×3.5×4.25 |
PE sheet production line features
Our company absorbs and digests foreign advanced technology and technology. The newly developed thick plate extrusion production line is mainly used for the production of PE and other plates. The thickness of the plate can be 20-60mm and the width of the plate is 750-1800mm.
The various matching parts of this production line equipment can use world famous brand products, combined with our company's many years of plate equipment manufacturing technology and experience, making it more reliable and perfect. The surface of the produced product is smooth and has small dimensional error, and has many advantages such as corrosion resistance and strong insulation
Product features
It has high strength, temperature resistance and good anti-corrosion performance. It can be filled, reinforced, toughened, strengthened, flame retardant, modified, and the surface can be embossed and frosted. High temperature (about 100 degrees), good physical and mechanical properties. Mainly used in chemical, chemical fiber, environmental protection, machinery and other related industries.
The main technical parameters
Equipment model | SJ-GS-2000 |
Product thickness | 1-30mm |
Product width | 600-2000mm |
Product length | 2400 (or custom length) |
Extrusion amount | 80-800kg/h |
Main screw diameter | 65-200mm |
